12 Gauge 1-1/4 Inch x .109 Inch Smooth Shank Plastic Collated Concrete Nails are designed for fastening wood to concrete, wood to steel, steel to concrete, carpet to concrete, drywall track, doors, windows, ceiling systems, and other construction materials. The 1-1/4 inch / 32mm length provides deeper penetration than shorter concrete nails, making it suitable for stronger fixing applications.
These SD series concrete nails are made from alloy steel / No.60 steel with galvanized coating for high hardness, long durability, smooth surface, anti-corrosion performance, and reduced jamming. The 0-degree plastic collation keeps nails aligned for fast loading and stable feeding in compatible concrete nail guns.
12 Gauge smooth shank concrete nails for nail gun fastening.
.109 inch shank diameter and 1-1/4 inch / 32mm nail length.
Galvanized surface for corrosion resistance and smoother feeding.
0-degree plastic-collated strips with 10 nails per row.
1,000 pcs per box and 10 boxes per case for construction and wholesale supply.
Compatible with CS3040 pneumatic nailer and many gas-powered concrete and steel nailers.
Watch the video to understand the concrete nail structure, plastic collation, and nail gun fastening performance.
These 12 Gauge concrete nails are supplied in 0-degree plastic-collated strips. The 1-1/4 inch / 32mm size is suitable for applications requiring deeper fastening into concrete, steel, masonry, filled block, or similar construction substrates.
| Attribute | Details |
|---|---|
| Product Name | 12 Gauge 1-1/4 Inch x .109 Inch Galvanized Concrete Nails |
| Series | SD Concrete Nails |
| Gauge | 12 Gauge |
| Main Size | 1-1/4 inch / 32mm |
| Length Range | 19mm–38mm |
| Angle | 0 degree |
| Material | Alloy steel / No.60 steel |
| Finish | Galvanized coating |
| Head Width | 6.1mm–6.3mm |
| Shank Diameter | 2.8mm–3.0mm / .109 inch–.118 inch |
| Shank Type | Smooth shank |
| Collation | Plastic collated |
| Packing | 10 pcs/row, 100 rows/box, 1,000 pcs/box, 10 boxes/case |
| Approx. Box Weight | About 4.1 lbs / 1.87kg per box |
| Compatible Tools | CS3040 pneumatic nailer and many gas-powered concrete and steel nailers |
SD concrete nails are engineered for stable nail gun fastening into concrete, steel, soft concrete, solid masonry, and filled block. The plastic strip keeps nails aligned for centralized loading, while the galvanized coating helps improve corrosion resistance and feeding stability.
Made from No.60 steel for high hardness and long durability.
Smooth surface with thick galvanized coating for anti-corrosion performance.
No-flash surface helps reduce jamming in compatible concrete nailers.
Plastic-collated strips reduce loosening and help improve loading efficiency.
Consistent .109 inch shank diameter and 1-1/4 inch / 32mm length.
10 pcs per strip and 1,000 pcs per box for construction site and distributor supply.
Suitable for doors, windows, ceilings, drywall track, wood-to-concrete, wood-to-steel, and steel-to-concrete fastening.
The SD series includes 19mm, 22mm, 25mm, 32mm, and 38mm concrete nails. The 1-1/4 inch / 32mm SD32 size is designed for deeper fastening depth, while other lengths can be selected according to the substrate and fixture thickness.
| Item | Specification | Length (mm) | Length (inch) | Pcs/Stick | Pcs/Box |
|---|---|---|---|---|---|
| SD19 | 12GA SD Series | 19mm | 3/4" | 10 pcs | 1,000 pcs |
| SD22 | 12GA, .109 inch shank diameter | 22mm | 7/8" | 10 pcs | 1,000 pcs |
| SD25 | Wire diameter .109 inch–.118 inch | 25mm | 1" | 10 pcs | 1,000 pcs |
| SD32 | Head width 6.1mm–6.3mm | 32mm | 1-1/4" | 10 pcs | 1,000 pcs |
| SD38 | 12GA SD Series | 38mm | 1-1/2" | 10 pcs | 1,000 pcs |
KYA supplies multiple plastic-collated concrete nail sizes for different fastening depths and base materials. Buyers can select the correct nail length according to fixture thickness, substrate type, nailer compatibility, and holding strength requirements.
These 1-1/4 inch smooth shank concrete nails are suitable for fastening to soft concrete, solid masonry, filled block, and steel. They are commonly used by construction contractors, drywall installers, ceiling installers, window and door installers, flooring installers, fastener wholesalers, and tool distributors.
Fastening wood to concrete.
Fastening wood to steel.
Fastening steel to concrete.
Fixing carpet to concrete.
Installing drywall track, doors, windows, and ceiling systems.
Fastening to soft concrete, solid masonry, and filled block.
To reduce jamming and improve fastening stability, buyers should confirm nail length, shank diameter, collation angle, nailer compatibility, and base material before ordering. The 1-1/4 inch / 32mm nail is suitable for deeper fastening requirements, while shorter sizes may be selected for thinner fixtures.
| Selection Factor | Recommendation |
|---|---|
| Nailer Compatibility | Confirm compatibility with CS3040 pneumatic nailer or gas-powered concrete and steel nailers. |
| Nail Length | Use 32mm / 1-1/4" for deeper fastening, or select 19mm, 22mm, 25mm, or 38mm for other fixture thicknesses. |
| Base Material | Use for soft concrete, solid masonry, filled block, steel, and selected construction substrates. |
| Surface Finish | Select galvanized nails when corrosion resistance and smooth feeding are required. |
| Packing Requirement | 1,000 pcs per box and 10 boxes per case are suitable for construction projects and wholesale supply. |
KYA Fasteners supplies concrete nails, steel nails, plastic-collated nails, pneumatic nailers, gas nailer fasteners, industrial fasteners, staples, and fastening solutions for global distributors, contractors, construction suppliers, and tool dealers.
12 Gauge SD series concrete nails for nail gun fastening.
1-1/4 inch smooth shank nails for concrete, steel, masonry, and filled block applications.
Multiple lengths available from 19mm to 38mm.
Plastic-collated strips for fast loading and stable feeding.
Support for bulk orders, sample orders, custom packaging, and distributor supply.
They are used for fastening wood to concrete, wood to steel, steel to concrete, carpet to concrete, drywall track, doors, windows, ceilings, soft concrete, solid masonry, and filled block.
The main size is 1-1/4 inch, equal to 32mm. The shank diameter is .109 inch, and the nails are supplied in 0-degree plastic-collated strips.
These concrete nails are compatible with the CS3040 pneumatic nailer and many gas-powered concrete and steel nailers. Buyers should confirm nail length, shank diameter, and collation compatibility before ordering.
They are made from alloy steel / No.60 steel with a galvanized coating. This helps improve hardness, durability, surface smoothness, anti-corrosion performance, and fastening reliability.
Available lengths include SD19 3/4" / 19mm, SD22 7/8" / 22mm, SD25 1" / 25mm, SD32 1-1/4" / 32mm, and SD38 1-1/2" / 38mm.
The standard packing is 10 nails per stick, 100 sticks per box, and 1,000 pcs per box. The product page also lists 10 boxes per case for bulk supply.
Yes. These smooth shank plastic-collated concrete nails can be used for steel-to-concrete fastening, wood-to-steel fastening, wood-to-concrete fastening, and other construction fastening applications when matched with a compatible nailer.
Bulk buyers include fastener distributors, tool dealers, construction contractors, drywall installers, ceiling installers, flooring installers, and building material wholesalers.
