KYA 16 gauge L-shaped flooring cleats are designed for professional nail-down installation of compatible tongue-and-groove hardwood flooring. The series includes L38 at 1-1/2" (38 mm), L45 at 1-3/4" (45 mm) and L50 at 2" (50 mm), providing three common fastener lengths for different flooring profiles, subfloor conditions and installation requirements.
Each cleat uses an L-shaped flooring head, barbed body and straight-strip collation for compatible 16 gauge flooring nailers. The current KYA packing specification lists 1,000 cleats per box and 10 boxes per carton for L38, L45 and L50.
16 gauge flooring cleat: professional fastener format used by many hardwood flooring nailer systems.
Three lengths: 1-1/2", 1-3/4" and 2" options for different flooring and subfloor combinations.
L-shaped head: designed for installation through the tongue of nail-down wood flooring.
Barbed cleat profile: provides mechanical engagement with compatible wood and subfloor materials.
Formed point: designed for efficient penetration into suitable wood flooring assemblies.
Straight-strip collation: designed for compatible manual and pneumatic 16 gauge L-cleat flooring nailers.
1,000 pcs per box: commercial packaging suitable for flooring contractors, wholesalers and distributors.
| Model | Length | Gauge | Pcs / Box | Boxes / Carton |
|---|---|---|---|---|
| L38 | 1-1/2" / 38 mm | 16 Gauge | 1,000 | 10 |
| L45 | 1-3/4" / 45 mm | 16 Gauge | 1,000 | 10 |
| L50 | 2" / 50 mm | 16 Gauge | 1,000 | 10 |
Do not select cleat length solely by flooring thickness. The correct length also depends on the tongue position, flooring construction, subfloor thickness, fastener penetration and flooring manufacturer's installation requirements.
The three L-cleat lengths overlap across many professional flooring applications. Major flooring-tool manufacturers do not assign one fixed cleat length to only one flooring thickness, so buyers should treat the following as selection guidance rather than a universal installation rule.
| Model | Length | Selection Guidance |
|---|---|---|
| L38 | 1-1/2" | Shorter option for compatible flooring profiles where the flooring and tool manufacturers specify a 1-1/2" 16GA cleat. |
| L45 | 1-3/4" | Intermediate length when more penetration than 1-1/2" is required but a full 2" cleat is unnecessary. |
| L50 | 2" | Common long 16GA L-cleat for 5/8" and 3/4" nail-down hardwood flooring where sufficient subfloor penetration is required. |
L-cleats are purpose-built for nail-down tongue-and-groove wood flooring. A flooring nailer positions the fastener through the tongue at the required angle while the tool base registers against the flooring surface.
The L-shaped head provides a defined seating surface, while the barbed cleat body engages with the wood substrate. The finished installation remains concealed as the groove of the next board covers the fastener location.
The characteristic L-shaped head is designed specifically for flooring-cleat installation. The formed barbs along the cleat provide additional mechanical engagement with compatible wood after the fastener is driven.
This geometry is widely used by professional hardwood flooring fastener manufacturers. Actual holding performance and the risk of tongue damage depend on the wood species, flooring profile, fastener gauge, nail length, subfloor, moisture content and installation technique.
Professional 16 gauge flooring-nailer systems commonly cover tongue-and-groove flooring between approximately 1/2" and 3/4", while some fastener systems are also listed for thicker hardwood flooring.
However, flooring thickness alone does not determine the cleat length. Two flooring products of the same nominal thickness can have different tongue heights, core constructions and subfloor requirements.
| Flooring Type | What to Confirm Before Selecting the Cleat |
|---|---|
| Solid Hardwood | Floor thickness, tongue location, species, subfloor thickness and required fastener penetration. |
| Engineered Hardwood | Confirm that the manufacturer permits nail-down installation with 16GA L-cleats and specify the permitted length. |
| Dense Hardwood | Check whether the flooring manufacturer recommends 16GA cleats or a thinner fastener to reduce tongue damage. |
| Bamboo or Specialty Flooring | Use only when the flooring manufacturer explicitly permits 16GA L-cleats for that product. |
3/4" solid hardwood: common nail-down application for 16 gauge L-cleats.
5/8" hardwood flooring: supported by many professional 16 gauge flooring-nailer systems.
Selected 1/2" flooring: when the tool base, flooring profile and manufacturer permit a 16 gauge cleat.
Oak flooring: nail-down tongue-and-groove installations using compatible flooring nailers.
Maple flooring: compatible professional hardwood flooring applications.
Walnut flooring: nail-down flooring where 16 gauge cleats are specified.
Hickory flooring: use according to the flooring manufacturer's fastener recommendations.
Selected engineered flooring: only where the flooring manufacturer permits 16 gauge L-cleat fastening.
Discuss Your Flooring Application
KYA L38, L45 and L50 belong to the same general 16 gauge L-cleat platform used by many established professional flooring nailers. Always verify the exact tool model and accepted fastener length before ordering.
| Tool Family | Published 16GA L-Cleat Range |
|---|---|
| Powernail Model 45 / 45R | 1-1/2", 1-3/4" and 2" 16 gauge L-cleats. |
| Powernail 445 Series | 1-1/2"–2" 16 gauge L-cleats. |
| BOSTITCH MFN-201 | 16 gauge L-shaped flooring cleats in 1-1/2" and 2" lengths. |
| BOSTITCH MIIIFN | 16 gauge L-shaped flooring cleats from 1-1/2" to 2". |
| SENCO SHF200 | 1-1/2", 1-3/4" and 2" 16 gauge L-head flooring cleats. |
| Primatech P250AL / P250FL L-Cleat Versions | 1-1/2", 1-3/4" and 2" 16GA L-type flooring nails. |
| DEWALT DWFP12569 | 16 gauge L-shaped cleats from 1-1/2" to 2". |
| Freeman PDX50Q Series | 16 gauge L-cleats from 1-1/2" to 2" on compatible flooring-tool configurations. |
Brand compatibility should not be assumed from the gauge alone. Check cleat gauge, L-head profile, length, strip dimensions and the exact flooring-nailer model.
The Powernail Model 45 and pneumatic 445 Series are established 16 gauge L-cleat flooring nailers. Their published fastener range includes 1-1/2", 1-3/4" and 2" cleats, corresponding to the KYA L38, L45 and L50 length range.
The Powernail 445 is commonly used for approximately 5/8"–3/4" domestic hardwood flooring, while the manual Model 45 is primarily positioned for traditional tongue-and-groove hardwood installation.
The Powernail 50P and 2000F should not be listed as standard compatible tools for this product family.
The Powernail 50P uses an 18 gauge flooring cleat platform, while the Powernail 2000F uses a thinner 20 gauge flooring fastener platform. KYA L38, L45 and L50 are 16 gauge L-cleats and belong to the Model 45 / 445 class instead.
BOSTITCH MFN-201 is a manual hardwood flooring nailer specified for 16 gauge L-type flooring cleats. Its published fasteners include 1-1/2" and 2" cleats.
BOSTITCH MIIIFN is the corresponding pneumatic flooring-cleat platform and also supports 16 gauge L-shaped flooring cleats in the common 1-1/2"–2" range.
The SENCO SHF200 uses straight-strip 16 gauge L-head flooring cleats in 1-1/2", 1-3/4" and 2" lengths. SENCO's corresponding fastener range is supplied at 1,000 pieces per box, matching the main KYA L38 / L45 / L50 size structure.
Primatech P250 flooring nailers are produced in several configurations. The P250AL and P250FL 16GA L-cleat versions are designed for L-type flooring nails in 1-1/2", 1-3/4" and 2" lengths.
Because the P250 family is also available for T-cleats and flooring staples, always confirm that the exact tool is fitted with the 16GA L-cleat magazine.
The DEWALT DWFP12569 flooring tool accepts 16 gauge L-shaped cleat nails from 1-1/2" through 2". It is supplied with interchangeable base plates for approximately 1/2", 5/8" and 3/4" flooring.
Sixteen gauge L-cleats are widely used for traditional solid hardwood flooring and many compatible engineered flooring products. Thinner 18 gauge cleats are available for applications where the flooring or tool manufacturer specifies a smaller fastener.
Dense exotic wood, bamboo and thinner engineered flooring can require a different gauge or shorter fastener. For these materials, follow the flooring manufacturer's installation instructions rather than automatically selecting a 16 gauge L-cleat.
The L-shaped head and flooring-cleat profile are designed to support professional tongue-and-groove installation, and major flooring fastener manufacturers describe this geometry as helping reduce the risk of tongue splitting.
However, no flooring fastener can guarantee zero splitting. Results depend on wood species, moisture content, tongue thickness, cleat gauge, cleat length, tool condition, air pressure and installation technique.
Correctly selected and installed flooring cleats help secure flooring boards to the subfloor, but floor squeaks can have multiple causes, including subfloor movement, joist movement, improper spacing, moisture changes and installation conditions.
For this reason, the fastener should not be described as guaranteeing a squeak-free floor. Use the spacing, cleat length and installation method specified by the flooring manufacturer.
KYA's current product information lists 1,000 cleats per box and 10 boxes per carton for L38, L45 and L50.
The page also lists approximately 45–60 boxes per pallet. Final pallet configuration can vary according to product size, export packing and order requirements, so confirm pallet quantities when requesting a quotation.
For an accurate quotation, provide the required L38, L45 or L50 size, quantity, destination market, flooring thickness, flooring type, subfloor material and flooring nailer model.
If the cleats will be used for engineered flooring, bamboo, reclaimed wood or dense exotic species, include the flooring manufacturer's fastener requirements so the appropriate cleat gauge and length can be confirmed.
The current KYA page lists a minimum order quantity of 50 boxes and indicates that sample quantities can be arranged. Confirm current MOQ, sample quantity, freight terms and export packing when requesting pricing.
KYA lists L38 at 1-1/2", L45 at 1-3/4" and L50 at 2", all in the 16 gauge L-shaped flooring cleat series.
Two-inch L50 cleats are commonly used for 3/4" hardwood flooring, but 1-1/2" and 1-3/4" 16 gauge cleats are also used in professional flooring systems. Follow the flooring manufacturer's installation specification and required subfloor penetration.
No. A 1-1/2" 16 gauge L-cleat can be used with multiple compatible flooring thicknesses depending on the flooring profile, subfloor and tool. It should not be limited to one flooring thickness category.
Yes, 1-3/4" 16 gauge L-cleats are used in compatible tongue-and-groove hardwood flooring systems. Confirm required penetration and the flooring manufacturer's fastener specification.
Professional 16 gauge flooring-nailer systems commonly support 2" L-cleats for 5/8" hardwood flooring. Verify the flooring profile and subfloor thickness before installation.
Yes, but only when the engineered-flooring manufacturer permits a 16 gauge L-cleat installation. Engineered flooring products vary significantly in thickness, core construction and tongue geometry.
Do not assume universal compatibility. Some bamboo and dense flooring products use thinner fasteners to reduce tongue damage. Follow the flooring manufacturer's fastening requirements.
The L-head and flooring-cleat design can help reduce tongue damage during proper installation, but splitting cannot be completely eliminated. Wood species, moisture, cleat length, tool setup and installation technique all affect the result.
No fastener can guarantee a squeak-free floor. Proper cleat spacing, subfloor condition, joist attachment, flooring moisture and installation technique all contribute to floor performance.
The Powernail 445 is specified for 1-1/2" to 2" 16 gauge L-cleats, covering the L38, L45 and L50 length range.
Yes, the Powernail Model 45 is specified for 1-1/2", 1-3/4" and 2" 16 gauge L-cleats.
No. The Powernail 50P uses an 18 gauge flooring cleat system and is not the same platform as KYA's 16 gauge L38, L45 and L50 cleats.
No. The Powernail 2000F uses a 20 gauge flooring fastener platform, so it should not be listed as compatible with 16 gauge L-cleats.
The BOSTITCH MFN-201 is designed for 16 gauge L-shaped flooring cleats and publishes 1-1/2" and 2" fastener sizes. Confirm the exact length supported for the installation before use.
Yes. The SENCO SHF200 publishes compatible 1-1/2", 1-3/4" and 2" 16 gauge L-head flooring cleats.
Primatech P250 tools are available in several configurations. The P250AL and P250FL 16GA L-cleat versions support 1-1/2", 1-3/4" and 2" L-type fasteners.
The DWFP12569 accepts 16 gauge L-shaped flooring cleats from 1-1/2" to 2", covering the KYA L38, L45 and L50 length range.
KYA lists 1,000 cleats per box for L38, L45 and L50.
The current KYA specification lists 10 boxes per carton.
The current product information lists approximately 45–60 boxes per pallet. Confirm final pallet configuration for the actual export order.
The current KYA product information lists a minimum order quantity of 50 boxes. Confirm the current MOQ with your quotation.
The current product information indicates that sample quantities can be arranged. Confirm the sample quantity, packing and freight terms with KYA.
Provide the required L38, L45 or L50 length, quantity, destination market, flooring type, flooring thickness, subfloor material and nailer model. For specialty or engineered flooring, include the manufacturer's fastener requirements.
KYA supplies L38, L45 and L50 16 gauge L-shaped flooring cleats for flooring fastener distributors, hardwood flooring suppliers, flooring contractors and professional installers. Send your required cleat length, quantity, flooring type and flooring nailer model to confirm the appropriate supply configuration.
