0.65*0.95*150
KYA
KYA-80 Wire Band
Width*Thickness*Pcs: | |
---|---|
Availability: | |
Quantity: | |
21 Gauge Staples Band Wire For 80 Wire Staples
The high-quality wire band is derived from high-quality raw materials and superb drawing technology, Reinforcement method upgrade-each roll of wire band is separated by the corrugated cardboard, to increase the pressure bearing capacity of the wire band.
The staple wire band is a kind of steel wire band for manufacturing staples, brads nails and pins nails etc.
Material : with ga anized steel wire or with the coppered steel wire or the stainless steel
Function :
1) More sofe,and power saving ,high effciency..
2) More firm ,our staples are the best choice.
Video:
Staples Band Wire Size:
Wire Dia. | For Staples | Gauge | Material Type | Our Spec. | Pcs/Strip | Finishing | Tensile Strength | |
Width(mm) | Thickness(mm) | |||||||
0.89 | A11 | 20 | QYL2 | 1.25 | 0.5 | 84 | Galvanized | 1000-1100N/MM⊃2; |
0.83 | 380 Staples | 21 | QYL2 | 0.91 | 0.7 | 150 | Galvanized | 1000-1100N/MM⊃2; |
1.19 | 90/92 | 18 | QYL2 | 1.27 | 1.05 | 100 | Galvanized | 1000-1100N/MM⊃2; |
1.19 | 90/92 | 18 | 45C | 1.27 | 1.05 | 100 | Galvanized | 1350-1400N/MM⊃2; |
0.67 | 71 Staples | 22 | QYL2 | 0.75 | 0.57 | 182 | Galvanized | 1000-1100N/MM⊃2; |
1.52 | 16 Staples | 16 | QYL2 | 1.58 | 1.38 | 70 | Galvanized | 950-1050N/MM⊃2; |
1.4 | 14 Staples | 17 | QYL2 | 1.45 | 1.3 | 75 | Galvanized | 950-1050N/MM⊃2; |
1.8 | 180 Staples | 15 | QYL2 | 1.84 | 1.63 | 60 | Galvanized | 950-1050N/MM⊃2; |
1.52 | 35 Carton Staples | 16 | Q195 | 2.21-2.25 | 0.82-0.84 | 50 | Copper coated or Galvanized | 450-550N/MM⊃2; |
1.52 | 35 Carton Staples | 16 | Q195 | 2.23-2.27 | 0.77-0.79 | 50 | Copper coated or Galvanized | 450-550N/MM⊃2; |
1.47 | 35/32 Carton Staples | 17 | Q195 | 2.19-2.23 | 0.72-0.74 | 50 | Copper coated or Galvanized | 450-550N/MM⊃2; |
1.63 | 35 Carton Staples | 16 | Q195 | 2.22-2.27 | 0.89-0.91 | 50 | Copper coated or Galvanized | 450-550N/MM⊃2; |
Wire Technical Parameter:
18 Gauge Staples Band Wire For 90/92 Staples Wire Material:
Wire Material | |||
Wire Dia | Material | Tensile Strength(N/mm2) | Coating Thickness(g/mm2) |
0.83-0.84 | C1018 | 1050-1100 | Zn 13-15 |
Description:
Description : Flattened wires glued into bands for production of industrial and office stapples.
Steel : 0,06 to 0,50 % carbon.
Tensite strenght : 450 to 1 400 N/mm2 .
Coating : Bright, galvanised, coppered.
Aspect : Neutral ou coloried.
1. Bands wire surface: Electrogalvanized
2. Flattening degree: The staple wire band can be made with any degree of flattening, technically possible to be done using wire of .0.70 -1.80 mm;
3. Bands' color: Translucent, golden (The color may be different as per customer request.)
4. The average weight of empty spool: 35kgs
5. Packing: The outside layer of band is protected by thin layer of removable plastic foam and adhesive tape.
Packing: according the customer's LOGO or the normal packaging.
21 Gauge Staples Band Wire For 80 Wire Staples
The high-quality wire band is derived from high-quality raw materials and superb drawing technology, Reinforcement method upgrade-each roll of wire band is separated by the corrugated cardboard, to increase the pressure bearing capacity of the wire band.
The staple wire band is a kind of steel wire band for manufacturing staples, brads nails and pins nails etc.
Material : with ga anized steel wire or with the coppered steel wire or the stainless steel
Function :
1) More sofe,and power saving ,high effciency..
2) More firm ,our staples are the best choice.
Video:
Staples Band Wire Size:
Wire Dia. | For Staples | Gauge | Material Type | Our Spec. | Pcs/Strip | Finishing | Tensile Strength | |
Width(mm) | Thickness(mm) | |||||||
0.89 | A11 | 20 | QYL2 | 1.25 | 0.5 | 84 | Galvanized | 1000-1100N/MM⊃2; |
0.83 | 380 Staples | 21 | QYL2 | 0.91 | 0.7 | 150 | Galvanized | 1000-1100N/MM⊃2; |
1.19 | 90/92 | 18 | QYL2 | 1.27 | 1.05 | 100 | Galvanized | 1000-1100N/MM⊃2; |
1.19 | 90/92 | 18 | 45C | 1.27 | 1.05 | 100 | Galvanized | 1350-1400N/MM⊃2; |
0.67 | 71 Staples | 22 | QYL2 | 0.75 | 0.57 | 182 | Galvanized | 1000-1100N/MM⊃2; |
1.52 | 16 Staples | 16 | QYL2 | 1.58 | 1.38 | 70 | Galvanized | 950-1050N/MM⊃2; |
1.4 | 14 Staples | 17 | QYL2 | 1.45 | 1.3 | 75 | Galvanized | 950-1050N/MM⊃2; |
1.8 | 180 Staples | 15 | QYL2 | 1.84 | 1.63 | 60 | Galvanized | 950-1050N/MM⊃2; |
1.52 | 35 Carton Staples | 16 | Q195 | 2.21-2.25 | 0.82-0.84 | 50 | Copper coated or Galvanized | 450-550N/MM⊃2; |
1.52 | 35 Carton Staples | 16 | Q195 | 2.23-2.27 | 0.77-0.79 | 50 | Copper coated or Galvanized | 450-550N/MM⊃2; |
1.47 | 35/32 Carton Staples | 17 | Q195 | 2.19-2.23 | 0.72-0.74 | 50 | Copper coated or Galvanized | 450-550N/MM⊃2; |
1.63 | 35 Carton Staples | 16 | Q195 | 2.22-2.27 | 0.89-0.91 | 50 | Copper coated or Galvanized | 450-550N/MM⊃2; |
Wire Technical Parameter:
18 Gauge Staples Band Wire For 90/92 Staples Wire Material:
Wire Material | |||
Wire Dia | Material | Tensile Strength(N/mm2) | Coating Thickness(g/mm2) |
0.83-0.84 | C1018 | 1050-1100 | Zn 13-15 |
Description:
Description : Flattened wires glued into bands for production of industrial and office stapples.
Steel : 0,06 to 0,50 % carbon.
Tensite strenght : 450 to 1 400 N/mm2 .
Coating : Bright, galvanised, coppered.
Aspect : Neutral ou coloried.
1. Bands wire surface: Electrogalvanized
2. Flattening degree: The staple wire band can be made with any degree of flattening, technically possible to be done using wire of .0.70 -1.80 mm;
3. Bands' color: Translucent, golden (The color may be different as per customer request.)
4. The average weight of empty spool: 35kgs
5. Packing: The outside layer of band is protected by thin layer of removable plastic foam and adhesive tape.
Packing: according the customer's LOGO or the normal packaging.
